Ajax MotionCam Outdoor PhOD
Ajax MotionCam Outdoor PhOD
Couldn't load pickup availability
Ajax MotionCam Outdoor PhOD
MotionCam Outdoor PhOD is a wireless outdoor motion detector that takes photos by alarm, on demand or by scenario that combine the best optics, fast processor and advanced software algorithms that takes informative pictures in any weather, day or night
Lightning-fast alarms. Verified.
MotionCam Outdoor PhOD recognizes intrusion from the very first steps on the property and confirms it with an animated series of photos (not video!!)
Visual verification helps to instantly ascertain the situation, saving users from concerns, and security companies from unnecessary patrol dispatches.
The MotionCam Outdoor is only compatible with the Hub 2 (2G), Hub 2 (4G), Hub 2 Plus and Rex 2
Lightning-fast alarms. Verified.
MotionCam Outdoor recognizes intrusion from the very first steps on the territory and confirms it with an animated series of photos (not video!!)
Visual verification helps to instantly ascertain the situation, saving users from concerns, and security companies from unnecessary patrol dispatches.
The MotionCam Outdoor is only compatible with the Hub 2 (2G), Hub 2 (4G) and Hub 2 Plus
*Compatible with Rex 2 only. Not compatible Rex (1) range extender.
Multilevel anti-sabotage protection
MotionCam Outdoor can not be unnoticeably disabled even if the system is disarmed. The detector is equipped with masking sensors reacting to hindering, covering and painting the lens.
It will take the hub less than a minute1 to detect the loss of communication with the detector and inform a central monitoring station and users about the problem. The fact that MotionCam Outdoor was dismantled will become known instantly.
Anti-masking systemNotifications about detachmentConfigurable detector ping interval
Intelligent false alarm filter
Correlation analysis
Whenever MotionProtect Outdoor detects motion, LISA analyses and compares signal forms from two sensors in real-time. If forms are similar, the alarm is raised.
Spectral analysis
When both sensors detect motion, but the correlational analysis doesn’t identify enough similarities, LISA compares frequency components in the signals of both sensors.
Additional information
| WEIGHT | 470 g |
|---|---|
| DIMENSIONS | 206 × 108 × 93 mm |
Technical Specifications
| Classification | Electro-optical radio channel security detector |
| Type of detector | Wireless |
| Installation method | Indoors / Outdoors |
| Recommended installation height | 0.8 – 1.3m |
| Compatibility | Hub 2 (2G & 4G), Hub 2 Plus Not compatible with ReX radio signal range extender |
| Sensing element | 2 × PIR sensor |
| Motion Detection Distance | Adjustable, from 3 to 15m |
| Pet immunity | Animals up to 80 cm tall (height of device) |
| Sensitivity | Adjustable, 3 levels |
| Motion detector’s viewing angle | Horizontal — 88,5° Vertical — 80° |
| Camera’s angle | Horizontal — 105° Vertical — 50° |
| TV distortion (EBU standard) | Barrel, –17% |
| Photo in case of alarm | Photo resolution:
Shooting series up to 5 photos |
| Infrared light for shooting in the dark | Available |
| Power supply | 4 × CR123A batteries |
| Supply voltage | 3V |
| Battery Life | Up to 3 years (up to 2.5 years if “Delay when entering” setting is activated)
Calculate battery life |
| Jeweller radio technology | Communication range with a hub — up to 1,700 m in an open space Two-way communication between hub and device Operating frequencies — 868.0–868.6 MHz3 Self-adjusting RF output power — up to 20mW Block encryption with a dynamic key Detector polling period — 12–300 s Frequency hopping |
| Alarm delivery time | 0.15 s |
| Wings radio technology | Transmission of a series of photos Photo delivery time with default setting: up to 9 seconds |
| Temperature sensor | Available |
| Operating temperature range | from -25°С to +60°С |
| Operating humidity | Up to 95% |
| Protection class | IP55 |
| Anti-sabotage | Anti-masking Protection against forgery Jamming detection Tamper-resistant |
| Remote set up and testing | Available |
| CMS compatibility | CMS connectivity: Contact ID, SIA (DC-09)
CMS software supporting visual alarms verification |
| Colour | White only |
| Dimensions | 206 × 108 × 93 mm |
| Weight | 470 g |
| Warranty | 24 months from the date of sale |
| Service life | 10 Years |
| Complete Set | MotionCam Outdoor motion detector SmartBracket mounting panel Hood visor 4 × CR123A batteries (pre-installed) Installation kit User’s guide |
