Ajax CombiProtect
Ajax CombiProtect – includes both Motion Detection and Glass Breaks in one device
Ready to operate out the box. Scan the QR code on the back of the device with your smartphone and it connects to the hub. It can be mounted using the SmartBracket in just a few minutes.
CombiProtect is a device combining a wireless motion detector with the viewing angle of 88.5° and distance up to 12 meters, as well as a glass break detector with the distance up to 9 meters. It can ignore animals and detects a person within the protected zone from the first step. It can operate for up to 5 years from a pre-installed battery and is used inside premises.
CombiProtect operates within the Ajax security system, connected to the hub via the protected Jeweller protocol. The communication range is up to 1200 meters in the line of sight. In addition, the detector can be used as a part of third-party security central units via the Ajax uartBridge or Ajax ocBridge Plus integration modules.
The Ajax security system is self-sustaining, but the user can connect it to the central monitoring station of a private security company.
The CombiProtect is a wireless indoor detector that combines both motion and broken glass detection. The device helps to secure the room from intruders entering through doors and windows and monitors the current state of the glass. It can detect motion in a room at a distance of up to 12m and registers broken glass at a distance of up to 9m from the window.
This smart device detects motion even in hot climates by means of temperature compensation. It filters false alarms caused by thunder, dogs barking and the sound of passing trucks.
Additional information
| WEIGHT | 92 g |
|---|---|
| DIMENSIONS | 110 × 65 × 50 mm |
| COLOUR |
Black, White |
Technical Specifications
| Classification | Electro-optical combined radio channel security detector |
| Device type | Wireless |
| Installation method | Indoors |
| Compatibility | Operates with all Ajax hubs, range extenders, ocBridge Plus, uartBridge |
| Sensing element | PIR sensor, electret microphone |
| Alarm signal delivery time | 0.15 sec |
| Motion detection distance | Up to 12 m |
| Detection angles | Horizontal — 88.5° Vertical — 80° |
| Time for motion detection | From 0.3 to 2 m/s |
| Recommended installation height | 2.4m |
| Pet immunity | Weight – up to 20kg Height – up to 50cm |
| Break detection distance | Up to 9m |
| Detection angle | 180° |
| Sensitivity | Adjustable, 3 levels |
| Power supply | Battery: CR123A battery, 3v |
| Battery life | Up to 5 years
|
| Jeweller radio technology | Communication range with detectors: up to 1,200m line of sight Two-way communication between devices Operating frequencies — 868.0-868.6 MHz Self-adjusting RF output power: up to 20mW Black encryption based on AES algorithm Detector polling period: 12 – 300 s Learn more about Jeweller |
| Temperature sensor | Available |
| Operating temperature range | from -10°С to +40°С |
| Operating humidity | Up to 75% |
| Anti-sabotage | Protection against fraud Jamming detection Tamper-resistant |
| Remote setting and testing | + |
| Dimensions | 110 x 65 x 50mm |
| Weight | 92g |
| Warranty | Replacement and repair for a period of 24 months of the date of sale. Batteries are not covered under warranty |
| Service life | 10 Years |
| Complete set | CombiProtect combined motion and glass break detector SmartBracket mounting panel CR123A battery (pre-installed) Installation set User’s guide |
